How to Self-Host n8n on Raspberry Pi 4 (ARM64) with Docker Compose

This guide shows a clean, reliable way to run n8n on a Raspberry Pi 4 using Docker Compose.

📝 Note: I want to use this setup primarily for AI workflows (transcription, summarization, RAG, content drafting).

What is n8n?

n8n is an open‑source, self‑hostable workflow automation tool.

You build automations by connecting nodes in a visual editor:

Triggers like webhooks, schedules/cron, IMAP, polling start a workflow; you transform data, branch logic, handle errors, and call services/APIs or databases.

It’s ideal for glue code and recurring tasks without writing and deploying full apps.

🚀 Core Capabilities

What you can build with n8n:

• API & Service Integration: Connect HTTP APIs and webhooks.
• Data Pipelines (ETL): Sync data across files, databases, and SaaS platforms.
• Ops & Incidents: Automated notifications, alerts, and response workflows.
• Internal Tools: Streamline back-office tasks and custom dashboards.
• AI & LLM Orchestration: Build RAG pipelines, transcription/summarization, chatbots, and automated data extraction.

🍓 Raspberry Pi Use Cases

Optimized for local, low-power edge computing:

🤖 Advanced AI Automations

Leveraging Large Language Models (LLMs) on your self-hosted instance:

📧 Smart Email Triage

For new messages, generate summaries and priority labels; draft reply suggestions with an LLM; route high‑priority items to a chat channel.

📂 Local RAG (Retrieval-Augmented Generation)

• Ingest: Watch /files/docs for new PDFs.
• Process: Generate embeddings and store in a Qdrant container.
• Query: Expose a webhook to answer questions based on your local data.

✍️ Content & Safety

• Auto-Drafting: For each RSS item, have an LLM generate a concise post with hashtags, then publish to Mastodon/Telegram; keep a dedupe key to avoid re-posts.
• Moderation: Redact PII (Personally Identifiable Information) using pattern matching and LLM verification before storage.

Installation

TL;DR / Quick Start

1. Check architecture (arm64 preferred):

   uname -m
   # aarch64 -> 64-bit, armv7l -> 32-bit


2. Create docker-compose.yml using the snippet below.
3. Set WEBHOOK_URL, GENERIC_TIMEZONE, and TZ for your locale.
4. Start: docker compose up -d
5. Open: http://raspi.local:5678 (or your Pi’s IP)
6. Logs: docker compose logs -f n8n — Stop: docker compose stop

Prerequisites

• Raspberry Pi 4
• Docker and Docker Compose

Check architecture (arm64 is preferred):

uname -m
# aarch64 -> 64-bit, armv7l -> 32-bit

Docker Compose file

Create a docker-compose.yml:

version: "3.8"
services:
  n8n:
    image: docker.n8n.io/n8nio/n8n
    restart: unless-stopped
    ports:
      - "5678:5678"
    environment:
      - N8N_ENFORCE_SETTINGS_FILE_PERMISSIONS=true
      - N8N_PORT=5678
      - N8N_PROTOCOL=http
      - N8N_RUNNERS_ENABLED=true
      - N8N_SECURE_COOKIE=false
      - NODE_ENV=production
      - WEBHOOK_URL=http://raspi.local:5678
      - GENERIC_TIMEZONE=Europe/Istanbul
      - TZ=Europe/Istanbul
    volumes:
      - n8n_data:/home/node/.n8n
      - ./local-files:/files

volumes:
  n8n_data:

Environment variables

• N8N_PORT: The port n8n listens on inside the container (mapped to 5678 on the host).
• N8N_PROTOCOL: http for local/LAN, https when behind a reverse proxy (e.g., Traefik) terminating TLS.
• WEBHOOK_URL: The externally reachable base URL n8n uses to generate webhooks and OAuth callbacks. Include scheme and port, e.g., http://raspi.local:5678 or https://n8n.example.com.
• N8N_SECURE_COOKIE: Set true when using HTTPS (prevents cookies over insecure transport); keep false for plain HTTP.
• N8N_RUNNERS_ENABLED: Enables n8n Runners to execute tasks in isolated processes/containers for performance and safety. If not using Runners, set to false.
• N8N_ENFORCE_SETTINGS_FILE_PERMISSIONS: Ensures secure permissions on settings files (helps protect secrets).
• NODE_ENV: Use production for better performance and fewer dev checks.
• GENERIC_TIMEZONE and TZ: Time zone for workflows and the container. Keep both aligned (e.g., Europe/Istanbul).

Volumes

• n8n_data: A volume mapped to /home/node/.n8n. n8n saves its SQLite database file and encryption key here.
• ./local-files: A local directory shared between the n8n instance and host. In n8n, use the /files path to read from and write to this directory.

Networking

• This example exposes n8n over HTTP on your LAN and does not use a domain name.
• For HTTPS and a domain, place n8n behind a reverse proxy like Traefik with Let’s Encrypt. Set N8N_PROTOCOL=https and WEBHOOK_URL to your HTTPS URL (e.g., https://n8n.example.com); let the proxy terminate TLS and route requests to the n8n container.

Start the stack

docker compose up -d
# Visit: http://raspi.local:5678 (or your Pi’s IP)

To see the n8n logs:

docker compose logs -f n8n

To stop the containers:

docker compose stop

Tips

• Replace raspi.local with your Pi’s hostname or IP.
• Updates: docker compose pull && docker compose up -d
• Backups: stop the stack and copy the n8n_data volume (contains the SQLite DB and encryption key).
• Local files backup: copy the host folder ./local-files (mapped to /files in n8n) to your backup location. You can copy it live, but stopping workflows avoids partial writes.
• HTTPS/domain: run n8n behind Traefik as a reverse proxy with Let’s Encrypt; set N8N_PROTOCOL=https and WEBHOOK_URL to your domain (e.g., https://n8n.example.com). The proxy handles TLS and forwards 443 traffic to n8n.

Troubleshooting

• Wrong WEBHOOK_URL or port leads to failing webhooks/OAuth. Use the exact external URL clients will reach.
• Permissions on ./local-files: if nodes can’t read/write, ensure the directory exists and is writable by the container user.
• Time zone drift: keep GENERIC_TIMEZONE and TZ consistent to avoid cron/schedule surprises.
• 32‑bit OS: the image may pull arm/v7. Prefer 64‑bit OS for better performance and compatibility.

FAQ

• What port does n8n use by default?
  • 5678 inside the container. This guide maps host 5678 to container 5678.
• Do I need HTTPS on my LAN?
  • Not strictly, but use HTTPS for remote access or when handling credentials. Put n8n behind a reverse proxy that terminates TLS and set N8N_SECURE_COOKIE=true.
• Where are my workflows and credentials stored?
  • In the n8n_data volume under /home/node/.n8n (SQLite DB and encryption key).
• How do I update n8n safely?
  • docker compose pull && docker compose up -d. Back up n8n_data first for rollback safety.

Helpful resources

• Docs home: https://docs.n8n.io/
• Docker deployment guide: https://docs.n8n.io/hosting/installation/docker/
• Community forum: https://community.n8n.io/
• GitHub (releases, issues): https://github.com/n8n-io/n8n
